Product features and benefits

  • Pre-wired, programmed, and tested
  • Touch screen technology
  • Remote or local pump start/valve opening sequence
  • Remote or local pump stop/valve closing sequence
  • Visual valve status indicators
  • Visual fault indicators
  • Remote fault indication
  • Fail-safe mode
  • Emergency stop button
  • Quick and simple field wiring

​Ball Valve


Material

  • Rugged, solid-state circuitry with adjustable timers
  • Push-to-test oil-tight lights
  • L-O-R selector switch
  • NEMA 4X fiberglass enclosure

The GA Industries Rotary Pump Control Valve is the only AWWA C507 Ball Valve specifically designed for pump control service. With advanced technology and a proven design, this valve offers the ideal combination of surge control during pump start-up/shutdown and virtually zero headloss during pump operation. The resilient ball valve design offers the longest life span available in today's market.

Meets American Iron and Steel requirements.

Pump Director

Material:

  • Body, Ball: Cast Iron, ASTM A126 Class B, or Ductile Iron, ASTM A536 Grade 65-45-12
  • Body Seat: Monel (Ni-Cu Alloy)
  • Ball Seat: Stainless Steel, Type 304
  • Shaft: Stainless Steel, ASTM A564 Type 17-4PH
  • Ball Bushing: Stainless Steel, Type 304
  • Body Bushing: Bronze, Alloy C93200


Corrosion protection:

  • High solids NSF-61 certified epoxy coating

Resilient Seated Ball Valve -Not Rubber

Metal Seated Ball Valve

​​​THE VALVE AGENCY, INC.


The GA Industries Resilient Seat Ball Valve is the only AWWA C507 Ball Valve specifically designed for pump control service. With advanced technology and a proven design, this valve offers the ideal combination of surge control during pump start-up/shutdown and virtually zero headloss during pump operation.The valve is equipped with a unique side access port that allows for easy maintenance. The Resilient Seated Ball Valve unlike any rubber seated valve. The life expectancy of the GA Resilient Seated Ball Valve is over 40 years, unlike that of a natural rubber design.


Meets American Iron and Steel requirements.

Made in Pennsylvania!


The Model 7700 Pump Director is the latest version of the time-proven GA Industries Pump Director, first introduce in 1975. The Pump Director is a pre-wired control panel to stop and start pumps and properly sequence the operation of the pump motor and the companion GA CHECKtronic®, Electric Check, or AWWA Ball Valve. The latest version incorporates enhanced features with touchscreen control, PLC-based logic, digital communication capabilities, five independently adjustable timers, and an emergency stop button.

Meets American Iron and Steel requirements.



​​Product Features and Benefits:

  • Rugged and dependable
  • Full port, unobstructed waterway
  • Quarter-turn design
  • Compact body with integral flanges
  • Trunnion-mounted rotor
  • Offset metal-to-metal seating
  • 6" - 48" Heavy Duty Cast or Ductile Iron body
  • Pressure class 150, 250, and 300
  • Hydraulic pneumatic, or electric motor actuation

​​Product Features and Benefits:

  • Rugged and dependable
  • Full port waterway
  • Virtually zero headloss
  • Long-term, low friction operation
  • Hydraulically actuated seat
  • Top entry body and side seat access port
  • 6" - 36" Heavy Duty Cast or Ductile Iron body
  • Pressure class 150, 250, and 300
  • Hydraulic, pneumatic, or electric motor actuation

Material:

  • Body and Cover: Cast Iron, ASTM A126 Class B, or Ductile Iron, ASTM A536 Grade 65-45-12
  • Body Seat Ring: Stainless Steel, Type 304 (Standard), Stainless Steel, Type 316 (Optional)
  • Rotor: Ductile Iron, ASTM A536 Grade 65-45-12
  • Rotor Seat: Ultra High Molecular Weight Polyethylene (UHMWPE)
  • Bearings/Bushings: Bronze, CDA 93200
  • Shaft: Stainless Steel, Type 303
  • Shaft Packing & Seals: Buna-N (Standard), EPDM (Optional)


Corrosion protection:

  • High solids NSF-61 certified epoxy coating
